COREFLEX® Waterproofing Membrane

Thermoplastic waterproofing membrane with active polymer core (APC)

Setting the standard for waterproofing membrane strength, durability and performance for more then 50 years. COREFLEX consists of a thermoplastic membrane integrally bonded to a proprietary Active Polymer Core (APC) layer. Combined with fully welded seams, this provides the ultimate waterproofing protection. Whether your project requires foundation waterproofing, plaza deck restoration, or green roof construction, COREFLEX provides superior waterproofing performance.

The COREFLEX reinforced thermoplastic membrane is engineered to resist high hydrostatic pressure and groundwater contaminants typical of foundation conditions. In addition to waterproofing performance, the membrane has an extremely low water vapor transmission that qualifies it as a Class “A” Vapor Retarder per ASTM E1745.



CoreFlex-wave-callouts

HydroshieldBanner-1

    Overview

    Dual membrane protection

    If COREFLEX’s thermoplastic membrane component is ever punctured or damaged, the superior water barrier performance continues with an APC technology layer that is engineered to actively control water ingress by swelling to produce a reliable seal at the breach. To maximize the performance of the APC Technology, the layer is installed in direct contact with the concrete to be waterproofed, thus preventing water ingress into the structure. With COREFLEX, each membrane overlap seam utilizes both a conventional weld and an overlap assembly of the APC Technology to assure water-tightness. This combination of passive and active barrier technologies provides enhanced seam performance and eliminates the reliance of seam integrity strictly on installation labor.



    Exceptional waterproofing performance

    Protection from water Ingress:

    • All seams are heat welded together to form a strong, monolithic waterproofing membrane.
    • Incorporating a high molecular weight plasticizer, the PVC membrane properties will remain intact through the life of the product.

    Protection from contaminants:

    • The APC and PVC resists harsh contaminants, including brownfield sites and remedial plaza decks over existing membranes.
    • COREFLEX can solve both water and gas barrier concerns as a Class “A” Vapor Barrier and Certified Methane Barrier (City of Los Angeles).

    Installation benefits and features:

    Fast and easy:

    • With remedial plaza-deck construction COREFLEX can be installed over most existing membranes, dramatically reducing exposure time of finished space.
    • No kettles, solvents, fumes or open flames necessary.
      Faster dry-in time than traditional systems.

    Versatility:

    • A true dual-membrane waterproofing system in a single application. The PVC layer of COREFLEX also serves as a root barrier, reducing the number of assembly components for green roof applications.
    Accessory Products

    Adhesive SB-100

    ADHESIVE SB-100
    Adhesive for securing COREFLASH membranes to various substrates, including cured concrete, wood, metal and cementitious boards.
    Learn more

    Akwaswell

    AKWASWELL
    Hydrophilic polyurethane caulk used for detail work including pipe penetrations.
    Learn more

    Cetseal

    CETSEAL
    A multi-purpose UV stable single component polyether moisture cure sealant/adhesive. Primary applications are grade termination sealant, membrane lap sealant and waterstop adhesive.
    Learn more

    CoreCap

    CORECAP TIE-BACK COVERS
    Preformed non-reinforced thermoplastic flashings, designed to provide a welded thermoplastic cover over tie-back heads on property line shoring walls; three preformed sizes available. CORECAP(S) used in conjunction with same size rigid TB-Boot.
    Learn more

    CoreClad

    CORECLAD
    A 24 ga. (0.61 mm) stainless steel sheet laminated on one side with thermoplastic polymeric coating for flashing applications.
    Learn more

    NoImage-Placeholder-2

    COREDISC
    A nominal 100 mm (4”) round x 1.5 mm (60 mil) non-reinforced thermoplastic disc. COREDISCS are used for T-joint patches and to repair small punctures in the PVC membrane.
    Learn more

    NoImage-Placeholder-2

    COREFLASH
    1.5 mm (60 mil) thick UV stable non-reinforced extruded white thermoplastic membrane used for detail and flashing applications including curbs, walls, field wraps and patches.
    Learn more

    NoImage-Placeholder-2

    COREFLASH NR
    1.5 mm (60 mil) thick UV stable non-reinforced extruded white thermoplastic membrane used for detail and flashing applications including curbs, walls, field wraps and patches.
    Learn more

    NoImage-Placeholder-2

    COREFLASH UV
    1.5 mm (60 mil) thick UV stable reinforced thermoplastic membrane (white top coat and black bottom coat) used for flashing applications exposed to direct UV and/or weathering conditions including curbs, walls, field wraps and patches.
    Learn more

    CoreTex

    CORETEX
    Active Polymer Core (APC) polymer impregnated geotextile for transition details, corners, butt-joints and protection from rough edges and surfaces.
    Learn more


    NoImage-Placeholder-2

    CORETEX XP
    Used with COREFLEX XP, CORETEX XP is a polymer impregnated geotextile featuring XP technology for transition details, corners, butt-joints and protection from rough edges and surfaces.

    Learn more

    300x220_InductionWeldingPlate

    INDUCTION WELDING PLATE
    80 mm (3.25 inch) diameter nominal metal plate with thermoplastic coating for attachment of COREFLEX membrane to shoring with induction welding machine.

    Learn more

    PF-150

    PF-150
    Molded non-reinforced thermoplastic flashings, specially designed for round penetrations 50 mm (2”) or less in diameter.

    Learn more

    PF-340
    Pre-fabricated factory welded thermoplastic pipe penetration sleeve with open cut side for simply installation around 75 mm (3 inches) to 100 mm (4 inches) pipe penetrations; comprised of a non-reinforced 60 mil membrane stack and a 60 mil reinforced membrane base flange.

    Learn more

    200x147_SEAL-X

    SEAL-X® XP
    A trowel-grade detailing mastic designed for a variety of surface preparation and detailing work. It swells upon contact with water to form a watertight barrier, even in high-saline water conditions.

    Learn more


    300x220_TW-Anchor

    TW-ANCHOR
    Specially designed anchors that allow for rebar to be tied into and supported without creating membrane penetrations.

    Learn more

    Universal Corner

    UNIVERSAL CORNER
    A molded non-reinforced thermoplastic flashings used to seal inside and outside corner details. Universal Corners come as one piece and are trimmed to fit the appropriate corner condition.

    Learn more

    Waterstop-RX

    WATERSTOP-RX®
    An active, flexible strip concrete construction joint waterstop, WATERSTOP-RX provides a strong positive seal by expanding upon contact with water. Proven effective on projects worldwide for over 20 years, Waterstop-RX is designed for both continuous and intermittent hydrostatic conditions. WATERSTOP-RX is available in multiple configurations.
